Category: AGITATOR-PUMP with immersed vertical axis.
Windings: Single-phase motor. Insulation Class F.
Motor body: Naked.
Protection: IP 00 ingress protection rating.
Safety: Built-in thermal motor protection system.
Ball bearings: Ø 6 mm bearings in a semi-rigid noise-damping silicone casing.
Motor shaft: AISI 303 INOX steel Ø 6 mm.
Fastening parts: INOX steel or corrosion-resistant materials.
Motor parts: N.A.
Cooling system: Air cooled pump with a suction speed of 1,2 m/s.
Water connection: Compatible with John Guest fittings.
Operation: Power supply 115 or 220-240 Volts – 24 hours a day non stop. Clean non drinkable water only.
Regulations: Check machine’s requirements.
Note: Read the instruction booklet for correct set up and use.
